Our Cell
Designation

Capacity at 10 Hr Rate as per IS 1651 Table 3

Overall Dimension
L + 5 TOL	W + 5 TOL	H + 15 TOL

Weight (Approx.)
With Acid	Without Acid

First Charge Current

Recharge Current
Upto 2.4 VPC	Till Full Charge

Kgs.

PBS 20

PBS 40

PBS 60

PBS 80

PBS 100

PBS 120

PBS 150

PBS 200

PBS 300

PBS 400

PBS 500

PBS 600

PBS 700

PBS 800

PBS 900

PBS 1000

20
40
60
80
100
120
150
200
300
400
500
600
700
800
900
1000

95	165	275
95	165	275
95	165	275
145	170	280
145	170	440
145	170	440
145	170	440
215	185	485
215	185	485
265	210	485
265	210	515
265	210	535
305	220	700
305	220	700
305	220	700
305	220	700

6	4.0
6.9	5.0
7.6	6.0
11.1	7.8
15.6	10.5
15.9	11.1
17.5	13.3
27	20
37	28
49	38
57	41
64	45
74	52
84	60
94	67
105	75

1
2
3
4
5
6
7.5
10
15
20
25
30
35
40
40
50

2	1
4	2
6	3
8	4
10	5
12	6
15	7.5
20	10
30	15
40	20
50	25
60	30
70	35
80	40
90	45
100	50

NOTE

1.0

Filling Sp.gr. of sulphuric Acid at 27 deg C

1.190

2.0

Final Sp.gr. of Sulphuric Acid after full }

1.200
charge at 27 Deg C } +/-0.005

3.0

Duration of First Charge

100 hrs. (Approx.)

4.0

Duration of Recharge in two steps

15 hrs. (Approx.)

5.0

'AH' capacity indicated is at 10 hrs. Discharge rate at 1.200 Sp.gr, +/- 0.005 of acid to an end Volrage of 1.85 V/Cell.

6.0

Voltage / Cell at the end of full charge

7.0

Higher Recharging current under Constant Potential charging is allowed subject to controlling the temperature within
55 Deg C. Most preferred Temperature is within 43 Deg C for deriving maximum life, Frequent recharging at a
temperature above 43 Deg C would drastically bring down useful service life.

8.0

Intermediate 'AH' capacities like 250AH, 350 AH ..... etc., is not covered in IS 1651 and therefore in the above
tabulation. It can be supplied if required.

9.0

Above cells are assembled in Hard Rubber container.

10.0

The above data is subject to change any time without notice as we constantly endeavour to improve the performance.

11.0

	TOL	:	Tolerance
	A	:	Ampere
	hrs./hr	:	Hours/hour
Abbreviations used :	AH	:	Ampere Hour V : Volts L : Length
	mm	:	Millimetre Approx. : Approximately W : Width
	Kgs.	:	Kilograms VPC : Volts / Cells H : Height
	Sp.gr.		Specific Gravity C : Centrigrade Deg. : Degree
